RCD Status: The yacht conforms with the essential safety requirements of Directive 94/25EC or RCDII (2013/53/EU as appropriate (Recreational Craft Directive) and is categorised Cat B – Offshore.

Hull Construction:

• Blue GRP hull, white superstructure.
• Stainless steel bow protection plate.
• Air draft (excl. Mast): 7’4” / 2.24m.
• Round bilge semi-displacement type hull – ¾ length deep keel, with flared bow.
• Rubber spray rails and all around 3″ rubber D fendering compliment the purposeful looks of the craft and provide extra protection when going alongside.
• Two anodes.
• White polyurethane boot top.
• Red antifouling paint.

Deck & Superstructure Construction:

• Grey non-slip paint to side decks and cockpit.
• Removable teak gratings to aft cockpit sole.
• This is a GRP moulding with substantial gunwales and wide non-slip decks incorporating a bevelled toe rail.
• The superstructure has a large vertical flange that overlaps with a similar flange on the hull before being through bolted and laminated to the hull.

Engine & Gearboxes:

• 2 x Yanmar 4JHA-STP (rated for 240hp@3300RPM) 3.455L 4-cylinder direct-injected diesel engines.
• Turbocharged and intercooled.
• Mores-type mechanical single lever gear/throttle controls.
• Final drive via ZF angled hydraulic reduction gearboxes.
• Engine bays are sealed off with bulkheads and are fully lined with sound insulation material including the hull section below the engines.
• Each engine fully independent with its own stainless steel fuel tank, fuel filter and start battery.
• Separ SWK-2000 clear-bowl primary fuel filters.

Maintenance & Performance:

• Engine hours: 740 @ January 2025.
• Engines last serviced: 2025.
• Cruising Speed: 14-18 knots.
• Quoted top Speed: 28 knots.
• 3000RPM  ~ 23 knots.
• 2500RPM ~ 16 knots.

Propulsion & Steering:

• Bennett electro-hydraulic trim tabs and indicators to helm.
• Tilt-adjustable steering wheel.
• Hydraulic steering linked to twin cast bronze air foil section rudders.
• Emergency tiller.
• Conventional shaft drives to bronze contra-rotating propellers with 3/4 length deep keel.
• Boat will rotate within its own length in either direction with one engine ahead and the other astern.
• Rope cutters fitted.

Voltage Systems:

• Power circuits are protected by Visi rocker circuit breakers mounted in a specially designed panel mounted on the forward wheelhouse bulkhead.
• 240 Volt ring main with power sockets.

Battery Banks:

• Two banks of twin 12 Volt batteries with isolating selector switches.
• A parallel switch is included to link the batteries together in the event one battery bank is discharged.

Battery Chargers:

• 12V Victron BluePower MultiPlus Compact 12V/1600S/70Ah smart battery charger with 1600W Inverter.

Alternators:

• 2 x Hitachi 12V/80Ah alternators.

Shore Power:

• 230V shore power inlet & cable.

Other Electrical:

• Digital Voltmeters.

Fresh Water & Water Heating System:

• Pressurized hot and cold-water system.
• 22 ltr calorifier water heater.
• Immersion heater to hot water tank.
• Fresh water pump.
• Shower discharge pump.
• Hot & cold cockpit shower.

Bilge Pumps:

• 3 x automatic bilge pumps with operation lights.
• Manual bilge pump at aft cockpit.

Fuel:

• Total fuel capacity of 700 litres in 2 x 350 litre independent tanks.
• Inspection lids for tank cleaning, and clear bowls to Separ primary bulkhead filters.
• Emergency fuel link valve to divert both fuel tanks to supply either engine in case one engine should breakdown.

Fresh Water:

• Total water capacity of 155 litres in single aluminium tank.

• Raymarine Hybrid Touch 9” colour display with GPS.
• Stand-alone Garmin GPSMap 276 Cx GPS colour plotter.
• Raymarine autopilot.
• 18-inch Raymarine closed radar.
• 2 x Raymarine instrument displays for depth, speed, log, position.
• AIS Class B transceiver.
• Raymarine Ray55E VHF.
• Cyclops Radar reflector.
• Horn.
• Plastimo steering compass.

Galley:

• Wallas Safe Flame diesel-fired two-zone hob.
• Panasonic 240V microwave oven.
• Stainless steel sink with hot/cold mixer taps.
• Drawers and cupboards fitted out for cutlery.
• Isotherm 42 litre refrigerator housed in unit below the navigators seat.

Heads/Showers:

• Heads with electric Jabsco WC (new 2024), hand basin and shower.
• Shower with electric pump out.

Heating & Ventilation:

• Eberspacher D4 diesel-fired hot air cabin heater.
• Two solar powered vent fans.
• Opening circular port-lights throughout accommodation.

Entertainment:

• Finlux flat-screen TV to wheelhouse.

Lighting:

• Flexi reading light at navigation position (red and white).
• LED cockpit lighting.
• Navigation & anchor lights.
• LED interior lights (some red night-vision lights).
• Aft deck flood/working light.
• Forward searchlight.

Summary of Accommodation:

• Eight opening port lights.
• Escape/deck hatch.
• Four slide-opening windows (one per side & 2 @ rear bulkhead).
• Cherry timber joinery with satin varnish finish.
• The interior surface finish is in melamine lacquer.
• Side and overhead linings are in vinyl or carpet as appropriate.
• Wheelhouse fitted with blond carpet.
• Cabin fitted with laminated teak & holly effect flooring.

Description of layout from forwards:

Fore Cabin:

• Forward cabin hatch.
• Access to chain locker.
• Vee berth with infill & cushions.
• Ensuite access to heads/shower compartment.
• Hanging locker with rail and fittings to hold table and leg.

Wheelhouse:

• The wheelhouse is arranged with the helm to port, the galley is non-gas and is located to starboard – aft of the navigators seat.
• The navigators position is to starboard with a desk locker for books and instruments.
• Red leather/Alcantara KAB suspension seats to helm and navigator’s positions (footrest to helm position, and hinged kickboard to navigator’s position).
• Twin full settee layout to wheelhouse.
• Port side wheelhouse has hinged pullman bunk berth.

Cockpit:

• The aft cockpit is self-draining, with smart cream seat cushions with blue piping, and backrest to aft bench.
• The forward part contains two hinged engine boxes with moulded in seats/steps.
• A full width bench seat is fitted across the stern with lift access to the steering gear and emergency steering.
• Hatches are fitted to the cockpit sole for access to the bilge and provide extra stowage space for ropes, fenders, and equipment.
• A socket is provided in the sole to enable the dining table to be set up in the cockpit for al-fresco dining.

General:

• Teak and stainless steel bathing platform complete with cassette-type boarding ladder.
• Stainless steel dinghy davits with launch/recovery lines & cleats.
• Outboard bracket.
• Stainless steel pulpit and stainless-steel grab rails (running well aft alongside decks).
• Twin pantographing screen wipers.
• Screen washers.
• 4 x stainless steel bollards.
• 2 x midships cleats in stainless steel.
• 2 x fairleads forward.
• Fixed polished stainless steel signal mast.

Anchoring & Mooring Equipment:

• Mooring warps & fenders.
• Galvanised Bruce-type anchor with galvanised chain.
• Electric windlass with self-stow/self-launching stem head fitting.
• 30 metres of 5/16 anchor chain & warp.

Covers, Canvas & Cushions:

• Cockpit cushions.
• Cockpit canopy full enclosure in blue canvas, with 5 windows and zip up entrances each side and at the stern.

• Two horseshoe life rings to wheelhouse roof.

Fire-Fighting Equipment:

• Manual fire extinguishers throughout accommodation (service dates unverified).
• Two automatic extinguishers to engine bays (service dates unverified).
• Fire blanket for galley.

The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
