• Design in accordance with European Directive requirements and according to CE certification
• Monolithic hull design in polyester
• Monolithic structural inner moulding bonded to the hull
• Injection moulded deck in glass fibre/balsa sandwich, covered with «diamond-point» non-slip coating
• Hull-deck join screwed, bonded and trimmed with 1 bulwark
• Cast iron keel fixed with bolts and stainless steel backing plates
• Rudder hung with glass composite stock
• White coloured hull - Grey metal hull graphics

RIGGING
• Standard mast 9/10 anodized aluminium installed on the deck, 2 aft-swept spreaders
• Anodised aluminium boom
• Discontinuous stainless steel standing rigging
• 2 Backstays with bottlescrews
• Rigid boom vang with tackle
• Genoa furling system with drum on the deck
• 2 Stand Up blocks for mainsail on fixed composite arch
• 2 Genoa tracks with piston adjusted traveller cars
• 2 Genoa sheet turning blocks
• Rigging run back to cockpit (except boom topping lift)
• Complete running rigging: Main halyard, genoa halyard with clutch on mast and cleat, Boom topping lift with cleat on mast, Mainsheet, 2 Genoa sheets 2 rapid reefing lines, 1 manual reef
• 7 Jammers
• 2 halyard bags

WINCHES
• 2 Self-tailing genoa sheet winches (H50.2 STC)
• 2 Self tailing coachroof winches (H40.2 STC)
• 2 Aluminium winch handles Speed Grip
• 2 Winch handle boxes

SAILS
• Furling genoa with UV protective strip
• Semi full batten written sail with slider and roller slider
• System: Lazy Jack and Lazy Bag in Natural colour

MOORING LINES -MOORING
• Self-bailing chain locker - Clench bolt - Hatch cover
• Single roller stainless steel bow fitting with offset roller
• 1 12 V - 1000 W vertical electrical windlass - Remote control
• 6 Aluminium mooring cleats - Stainless steel deck line protection

SAIL LOCKER
• Access through deck hatch T60
• Stainless steel ladder
• Shelving

SAFETY ON DECK
• 1 Open stainless steel forward pulpit - Step
• 2 Stainless steel pushpits
• 1 Lifebuoys support bracket
• 1 Outboard engine bracket
• Ring for flag welded on pushpit
• Double guardrail and stainless steel stanchions - Openings in guardrail to port and starboard

COCKPIT
• Self-draining cockpit
• 2 Cockpit locker
• 2 Lockers in cockpit sole beneath helm's feet
• 1 Liferaft locker under helm seat, in cockpit bottom (0,80 m x 0,40 m x 0,58 m / 2’7’’ x 1’4’’ x 1’11’’)
• 1 Gas locker for bottle(s) under the port helm seat
• Natural solid wood slatted cockpit benches
• 2 Steering wheel consoles: Stainless steel steering wheels - 900 mm diameter - Leather covered - Steering gear at the helm station - metal cable transmission system - Stainless steel handrail - navigation instrument support (optional instruments) - Cup holder
• 1 Deck filler for access to tiller system + Power supply access hatch
• 1 Tiller
• 2 Steering compass on binaccle
• Portside engine control and control panel
• Polyester cockpit table - 2 Leaves - miscellaneous locker - 2 Large storage space - 2 Stainless steel handrails - 12 V socket - lamp with shade
• 1 Cold water cockpit shower hose
• 1 Fixed composite arch - Integrated lights
• 2 Hinged PMMA companionway doors - Sliding hatch made of PMMA

SWIM DECK / STERN DECK
• Fully opening transom, convertible to bathing platform (2,85 m x 0,77 m /9’4’’ x 2’6’’)
• Electrically controlled opening
• Natural solid wood decking on swim platform
• 1 Stainless steel swim/boarding ladder - solid wood steps - folding

• Woodwork Alpi Mahogany
• Parquet type laminated floors
• Fabric hull linings in saloon and cabins (White)
• Fabric upholstery
• Marine mattresses in the cabins

COMPANIONWAY
• Headroom: 2,00 m / 6’7’’
• Wooden saloon companionway with moulded wood suspended steps with non-slip surface
• 2 Stainless steel handrails

SALOON
• Headroom: 1,97 m / 6’6’’
• U shaped saloon bench - double density foam
• Central seating on pantograph
• Saloon table in 1 piece - Varnished wood top with inlay - Aluminium legs
• Mirror on bulkhead
• Cupboards - Shelves and stowage along the hull - Storage under bench seats
• Shelves with stainless steel fiddles
• 2 Panoramic deck house windows with concertina blinds
• 2 Hull portholes with curtain
• 2 Opening portholes on coaming in side windows
• 1 Opening deck hatch with mosquito blind

CHART TABLE - PORT SIDE
• Sliding, can be configured with the armchairs - Placed against the forward bulkhead , against the galley or between the 2 mobile seats
• Table with flap - Moulded wood fiddle
• Switch panel on bulkhead for access to electrical functions
• 1 Reading light

GALLEY - PORT SIDE
• Headroom: 2,00 m / 6’7’’
• L-shaped galley
• Compact grey laminated worktop
• 1 Stainless steel sink 2 rectangular basins - 1 Mixer tap with hot/cold water under pressure
• 1 Gas cooker 2 burners - Stainless steel oven on mountings - Stainless steel protection handrail
• 1 85L / 22 US Gal icebox, top opening
• 1 130 L / 34 US Gal refrigerator (12V), front opening
• Fitted lockers and closed shelving (Shelving, Bin)
• 1 Base cabinet: 1 Drawer - 2 shelves
• 1 Opening portlight with curtains in side windows in the coaming
• Storage space along the hull

STARBOARD AFT CABIN
• Headroom: 1,96 m / 6’5’’
• 1 Double bed (2,05 m x 1,50 m x 1,15 m / 6’9’’ x 4’11’’ x 3’9’’) - Marine mattress
• Access door to starboard aft head
• Cupboards - Hanging locker - Closed shelving
• Stowage on both sides of berth
• 1 Hull portholes with curtain
• 1 Cockpit windows with curtains
• 1 Cockpit porthole with curtain
• 1 Flush deck hatch with mosquito blind

STARBOARD AFT HEAD COMPARTMENT
• Headroom: 1,88 m / 6’2’’
• Access through saloon and the starboard aft cabin
• Separate shower - 1 Hot/cold water mixer tap
• 1 Manual toilet
• 1 80 L / 21 US Gal rigid holding tank
• Basin - 1 Hot/cold water mixer tap
• Head cabinet
• 2 Mirrors
• Toilet accessories
• Cupboard
• 1 Opening portlight with curtains in side windows in the coaming

2 cabins layout

AFT-GALLEY (PORT AFT)
• Access via galley
• Large storage area (Numerous cupboards, shelves, Drawers)
• Access door to port cockpit locker
• 1 Flush deck hatch with mosquito blind

3 cabins layout

PORT AFT CABIN
• Headroom: 1,96 m / 6’5’’
• 1 Double bed (2,05 m x 1,50 m x 1,15 m / 6’9’’ x 4’11’’ x 3’9’’)
• Cupboard - Hanging locker - Closed shelving
• Stowage on both sides of berth
• 1 Hull porthole with curtain
• 1 Cockpit porthole with curtain
• 1 Flush deck hatch with mosquito blind
• 1 Cockpit windows with curtains

FORWARD CABIN
• Headroom: 1,89 m / 6’2’’
• Central double bed (2,05 m x 1,50 m x 1,15 m / 6’9’’ x 4’11’’ x 3’9’’)
• Hanger closets - Valet tray - Cubby hole locker - Base cabinet - Stowage under platform
• 3 Flush deck hatches with mosquito blind
• 2 Hull portholes with curtain

STARBOARD FORWARD HEAD COMPARTMENT
• Headroom: 1,85 m / 6’1’’
• Access through foward cabin
• Manual toilet
• 1 64 L / 17 US Gal rigid holding tank
• Moulded basin - Mixer shower (hot/cold water)
• Separate shower - 1 Hot/cold water mixer tap
• 1 Mirror
• Head cabinet
• Toilet accessories
• Cupboard
• 1 Flush deck hatch with mosquito blind

• Engine Yanmar Diesel 57 hp/57 HP Common Rail, Sail Drive
• Engine control - Control panel in the port cockpit
• Engine compartment: Soundproofing foam - Ventilation: 1 air intake and 1 pressured air outlet
• 1 Alternator 12 V / 125 Ah
• 1 Rotomoulded diesel tank 200 L / 53 US Gal (under port aft berth) - Electronic gauge - Low level alarm - 1 Deck filler
• Filters: Sea water - Diesel - Water separator
• Fixed three blades propeller
• 1 Engine access through companionway (opening with 2 gas struts) - 2 Engine access through aft cabins

• 12 V circuit
• 2 service batteries (110 Ah) - 1 Engine battery (110 Ah)
• 1 Power distributor
• 12 V Electrical panel (Fuses - Voltmeter - Water gauge - Fuel gauge - Battery warning - Fuel warning - Water warning)
• 1 12 V Sockets
• Lighting: Overhead lights - Reading lights - White striplighting
• Navigation lights: 1 Forward and aft navigation lights - 1 Engine navigation light / Spreader light forward of mast - 1 Anchor light on masthead
• Wire runs for options cables
• Full 220 V system (Interior sockets 220 V - 25 Amperes battery charger - Shore power socket)

• 1 Rotomoulded freshwater tank 330 L / 87 US Gal (Forward cabin) - 1 Deck filler
• Pressurised electric water pump - Expansion tank - Inline filter
• 40 L / 11 US Gal Electric calorifier (engine start)
• 1 Rigid black water holding tank for each WC
• Delayed shower draining and electric shower drain pumps
• 1 Electric bilge pump - 1 Manual bilge pump
• 1 Electric ice box drain pump

• 1 Gas bottle box in the cockpit (Diameter 0,34 m x 0,53 m / 1’1’’ x 1’9’’)
• Regulator and safety tap

Navigation electronics: B&G
• Wifi interface
• 4G Radar
• AC 42 autopilot + Control at steering station
• Chart table: Zeus 7’’ wide additional multifonction screen
• Chart table: Fixed B&G+V50 VHF, AIS receiver function + H50 cockpit handset
• WR10 Wireless autopilot remote control
• AIS 400
• Forward Scan Sensor (Forward underwater vision)

Rigging - Sails
• Anodized mast furling system with Mylar-Taffetas mainsail
• Asymmetrical spinnaker rigging + Code 0 rigging
• Self-tacking jib hardware
• Code 0 on "Top Down" furling system
• Self-tacking jib (replacing genoa)
• Self-tacking staysail with manual furling + Fixed forestay
• Additional bow roller - Stainless steel bobstay
• Releasable forestay chainplate
• Backstays with bottlescrews (Adjustable)*
• Genoa sheet track leads adjustable from the cockpit
• 2 flag halyards
* Except on mast with in-mast furling

Winches
• Electric genoa sheet winches - H46.2 STCEH / 50.2 STC

Hull - Deck - Cockpit
• Grey "Perle" hull
• Blue-grey hull
• Solid wood decking on cockpit sole
• Slatted solid wood side decks
• Polyester/wood cockpit table + White PVC protective covers
• Silver Coachroof sprayhood
• Silver Cockpit Bimini
• Dark Narval Cockpit cushions
• Bow thruster
• Refrigerated ice-box in cockpit table (30 L / 8 US Gal) - Positive cold
• 3 feathering blades propeller
• Stainless steel arch with davits
• White or black composite steering wheels
• Moorings lines, Mooring, Fenders
• Mooring cleats - Stern deck
• Windlass control in cockpit with chain counter
• White PVC steering wheel covers
• Shore freshwater supply
• Windex Windvane

Interior equipment
• Interior woodwork: Alpi satin light oak
• Luxe folding saloon table (double berth compatible)
• Interior upholstery: Fabrics, Leather, Ultraleather
• Upholstery padding (Saloon and Cabins): Anthracite Grey or Taupe
• TV LCD 24’’ + DVD player in the saloon
• Stainless steel 2 burner oven/grill cooker on Luxe mounting
• 220V Microwave oven
• Dishwasher (Available only in 2-Cabin version)
• Slat mattresses
• Double berth in saloon
• Quiet Flush electric toilet
• Extra water tank (200 L / 53 US Gal)
• Galley: Sea water/fresh water foot pump
• Mosquito nets
• 12/220 V, 2 kVA converter
• 6 KVA 220 V / 50 Hz Generator
• Forced air heating fuel
• 220 V / 50 Hz Air conditioning
• Water maker
