• Main Engines: Twin MTU 12V 2000 M96X (2 x 2000ps) Shaft Drive
  • Hours (08/25): Port/Stbd 285 hours
• Shafting: Two (2) x straight shaft supported by one (1) strut per side. PSS raw water lubricated dripless shaft seals
• Trim Tabs: Two (2) x Planning surface style, electro-hydraulic by PHOENIX SOLUTIONS.
• Engine Controls:
  • MTU-Xenta joystick manoeuvring system with dual station control.
  • MTU BlueVision Basic New Generation ships automation systems.
  • MTU RCS DUO-6k Engine propulsion twin control levers dual station.
  • MTU PAN 9 Operating Stop-start operating panel per engine and dual station.
  • MTU engine data displays on the Simrad screens on both consoles.
  • MTU LOP-13 Local operating panel with display in engine room per engine.
• Engine Cooling System: (two separate cooling circuits)
  • Engine coolant
  • Raw water with dedicated raw water intake (one (1) per engine) with strainer.
  • Coolant cooling by raw water-cooled plate-core heat exchanger
  • Thermostat-controlled coolant system
  • Coolant-cooled / preheated charge air
  • Coolant-cooled fuel return
• Steering System:
  • Electro-hydraulic system 24Vdc by SEASTAR
  • EP1600. Ram on port and STBD tiller arms
  • EC5810 - OPTIMUS. Port and STBD
• Thrusters:
  • Bow Thruster: Hydraulic Sleipner. Model SP550/386TC-BA40 500kg
  • Stern Thruster: Hydraulic Sleipner. Model SP550/386TC-BA40 500kg
  • Controlled using a Sleipner proportional joystick with dual station control.
• Stabilizers: CMC Stabilis Electra Fin stabilization system HS60 - 5kW 1.20 meter square fins.

• Generators: 2x Onan 29kw 60Hz (29MDKDS)
  • Hours (08/25): Port/Stbd 360 hours
• Shore Power:
  • 1x 100 Amp, 250V flexible cable w/ Glendinning Cablemaster motorized retraction system.
  • 1x 50 Amp, 125/250V flexible 4-core cable (20m length)
• Inverter: Victron Quattro 5kW inverter supplying regulated, uninterrupted power to the audio-visual system; Output: 5kVA, single phase, 120V 60Hz.
• Isolation Transformer: Energy Solutions 24kVA transformer providing galvanic isolation and stabilizing shore power voltage.
• Electrical Sockets:  Interior AC 110V 60Hz sockets - USA 3 pin
• Batteries
  • 4x 12V M110 batteries connected in series and parallel to provide 24V to engine bank
  • 6x 12V M135 batteries connected in series and parallel to provide 24V to domestic bank

AC System

• Air Conditioning: Two (2) x DOMETIC chillers – model: MCGXLP72 – 72,000BTU each – 208-230/60/3
• Circulating Pump: Dometic P100M-1171D-400-1 – 1/2T
• Raw Water Pumps: Dometic P075M-2371-330-1/2T

Fresh Water

• Fresh Water Maker: HRO Seafari 221 lt per hour (SFC 1400-2) including commercial pre filter, freshwater flush, and oil/water separator
• Fresh Water Purification: Flostream Hiflo 10 freshwater purifier serving the galley. Flostream Hiflo 2 freshwater purifier to all independent ice makers.
• Fresh Water Tank System with integral GRP tank of 1400 litres. WRAS approval for portable water. Pressure system via a Gianneschi Ecoinox 2CE AC self-priming pump and mounted with inlet/discharge manifold.
• Fresh water marina connection pressure regulator
• Hot Water Calorifier: Surejust horizontal 200 litre stainless steel cased tank with 2 x 2kW immersion heaters. 60 litre expansion tank.
• Hot water circuit ring main throughout the lower and main decks with a permanently running AC circulation pump.
• Second Hot water calorifier. Surejust horizontal 200 litre stainless steel cased tank with 2 x 2kW immersion heaters.
• Hand-held swimming shower. Whale twister
• Fresh water deck wash system with hose reel and outlets on Aft deck, Flybridge deck, and Fore deck

Waste & Sanitation Systems

• Grey Water: Grey water from showers and wash basins will drain directly to sump boxes of 100 litre capacity. Grey water from galley services will drain directly overboard. Sump boxes discharge the grey via 2x Whale Gulper 320 24Vdc pumping directly overboard.
• Black Water: holding tank system using one Polyethylene tank for main accommodation and crew of 400 litres. Discharge through either Sealand T-Series 24 Vdc self-priming diaphragm pump directly overboard (refer to MARPOL regulations) or to a shore facility when available.
• Toilet System: Total of six (6) heads TECMA 24V freshwater flush system

Fuel Polishing System

• Separ FPS-210 to eliminate the buildup of algae and water in the tank with 99.8 percent water

Miscellaneous Equipment

• Underwater lights: Lumishore TIX403 LED x 8 - Dual colour white / Blue. Four across the stern and two either side.

• Fuel capacity 11,000 litres / 2,907 US gal
• Fresh water capacity 1,400 litres / 370 US gal
• Black water capacity 400 litres / 106 US gal
• Crew Black water capacity 135 litres / 35 US gal
• Water Maker: HRO Seafari 221 lt per hour (SFC 1400-2) including commercial pre filter, freshwater flush, and oil/water separator

Lifesaving

• International running light: Green side light, red side light, white stern light, white masthead light, 360 white anchor light.
• Searchlight: Sanshin HR-1012 twin-beam halogen searchlight with remote control.
• Personal Floatation Device (PFD): Sixteen (16) Type II Adult size
• Throwable Devices: One (1) x Type IV – model: 5000 throwable
• Life Raft/ Floats: One (1) x DUARRY – s/n: DYSR-8-23/0017 – Manufactured in 03/2023 – 8 people. (Next service: August 2027)
• Horn: AFI Dual trumpet -11018 XLPD/24V

Fire Hydrant & Bilge Systems

• Bilge arrangement is divided into three compartments. Accommodation, Machinery and Crew. Monitored by the ship's monitoring system.
• Accommodation watertight space - 1 x 24V Rule 2000 bilge pump and 1 x 24V Rule 3700 bilge pump with dedicated float switches. In addition, the space forward of the engine room bulkhead and aft of the water-tight stabiliser compartment has 2 x 24V Rule 500 bilge pumps with dedicated float switches that will pump the water to the watertight bilge area to be extracted.
• Machinery space - 1 x 24V Rule 2000 bilge pump and 1 x 24V Rule 3700 bilge pump with dedicated float switches.
• Crew space - 1 x 24V Rule 2000 bilge pump and 1 x 24V Rule 3700 bilge pump with dedicated float switches.

Fire Suppression and Detection

• Fireboy-Xintex Fire alarm detection system. Model FR-2000 control panel with dedicated Discovery Smoke/heat detectors in all accommodation areas. Connected to the CM8 monitoring system to repeat alarm.
• Fireboy GA2 Series fixed machinery space fire extinguishing system using Novec 1230 extinguishing agent. The system is fully automatic, incorporating main engine, generator, and engine room ventilation shut-down with a mechanical manual over-ride pull in the side deck fire locker.
• 9x Portable dry powder fire extinguisher 1kg 5A 34B C
• Fire Suppression: One (1) x Clean agent by SEA-FIRE fixed tank in engine room, with CO2 & nitrogen pilot cylinders.
• RINA Fire bucket 3 gallon with line
• Fire Blanket. Ocean Safety FIR0022. 1.1 x 1.1 M

Alarms

• 1x floating switch style high water alarm sensors in master cabin
• 2x floating switch style high water alarm sensor the engine room
• 2x floating switch style high water alarm sensor in lazarette.

Security System

• CCTV system with camera facing the swim platform – model: GC255

• Marine Radio
  • GARMIN VHF 315
  • Wheelhouse: GARMIN GHS 11 handset
  • Flybridge: GARMIN GHS 11 handset
  • Crew: GARMIN GHS 11 handset
• Starlink System
• Pepwave 5G System

Flybridge Helm Station

• 2x Garmin GPSMAP 8622 16" multi-functional displays with remote input device
• Garmin Autopilot GHC 50  control display
• Garmin GHS11 VHF repeater handset with active speaker

Main Deck Helm Station

• MTU BlueVision Basic New Generation ships automation systems.
• MTU RCS DUO-6k Engine propulsion twin control levers dual station.
• MTU PAN 9 Operating Stop-start operating panel per engine and dual station.
• MTU engine data displays on the Simrad screens.
• MTU-Xenta joystick manoeuvring system with dual station control.
• Two Garmin GPSMAP 8616 22" Multi-functional displays with Garmin remote input device and SD Card reader.
• Garmin GPSMAP 8612 12" Multi-functional display
• Garmin GRM Fantom 126, 6ft Open array, 96nm.
• Garmin GPS 24XD Antenna.
• Garmin Autopilot GHP Reactor 40 with GHC 50 Control display.
• Garmin 315 VHF radio with Class D DSC, 2.4M whip VHF antenna.
• Garmin GSD25 sonar module for fish-finding and bottom tracking with Pair of Garmin GT51M-THP transducers and a DST810 for speed and temperature.
• Garmin Automatic Identification System AIS 800 transceiver system with dedicated VHF and GPS receiver.
• Ultrasonic Wind Sensor.
• Richie Helmsman HF-743B Flush Mount Magnetic Compass.
• 4 ST Sanshin Twin Beam remote-controlled Halogen Searchlight HR-1012

Ship’s Monitoring System

• Sunseeker CM8 integrated power management, boat monitoring, and control system.
• 10” touchscreen at lower helm; 7” touchscreen at flybridge helm
• Monitors and controls:
• AC Power: Generator status, voltage, current, frequency
• DC Power: Battery voltages, currents, and switch status
• Tank Levels: Fuel, fresh water, grey, and black water
• System Loads: Water heaters, pumps, chillers, air conditioning, nav lights, bilge/flood systems
• Alarms: Bathing platform door, platform position, shore power trip, system alerts
• Wiper System: Integrated synchronized control

Flybridge Helm

• Upper Helm Station with dual helm seats stbd forward
• Helm Instrument Cover in Stamoid Light - Pearl Grey

Flybridge

• Port forward lounge seating
• Wetbar with clear glass raised shelf and integrated LED lighting
• 2x Frigoboat MS130 stainless steel drawer refrigerators with water-cooled compressors
• Icemaker - Hoshizaki IM-30CNE
• Kenyon Electric BBQ grill
• Hardtop with retractable centre canopy and aft extending sun canopy in black
• Wraparound banquette seating
• Teak table with folding top extension and stainless steel legs
• Stern sunbather/lounge seating
• Companionway hatch at top of stairs from aft cockpit to flybridge deck
• Covers for seating, sunpad, table, and helm seats in Stamoid Light – Pearl Grey
• Teak decking throughout
• Boat Crane/Davits: Pre-rigged for future hydraulic crane installation
• Fresh water deck wash system outlet
• Preparation for future option to ad spa tub, including water supply, drainage, and power

Foredeck

• Mooring Bollards in polished stainless steel fitted port and starboard.
• Windlasses: Twin Lewmar V8 24V DC Windlass (Vertical Gypsy and Capstan drum)
• Capstans: Integrated in Lewmar Windlass units
• Anchors:
  • One Lewmar 80kg galvanised Claw anchor
  • One Lewmar 50kg galvanised Claw anchor
• Anchor Chains: 12mm high tensile galvanised short link chain with anchor swivel.
  • 1x 100 meters
  • 1x 60 meters
• Freshwater pressure washing of chain with directed outlet
• Stainless steel LED courtesy lighting from aft cockpit to bow on side decks and bow seating
• Teak Table with stainless steel legs
• U-shaped seating
• Fresh water deck wash system outlet
• Teak decking

Aft Deck

• Loose lounge/seating area with 1x sofa, 2x accent chairs, and 2x low-profile coffee/accent tables
• Mooring Bollards in polished stainless steel fitted port and starboard.
• Spring cleats x two sets in polished stainless steel fitted port and starboard on bulwark.
• Stern capstan winches - two Lewmar C4 24 Volt DC vertical capstans fitted port and starboard
• Stairway to flybridge
• Passarelle: Besenzoni Passerella telescopic Art 383.50 SS
• Aft Docking Station with MTU joystick manoeuvring system control
• Dometic 50 litre CR50 Cockpit Refrigerator
• Teak decking
• Manual sliding glass doors to main salon

Swim Platform

• Hydraulically lifting platform with maximum lift capacity of 650 kg, with Tender maximum weight of 550 kg
• Teak decking
• Stern spring cleats located on the aft edge of the hull for stern mooring
• Pair of Retractable Cleats for tender on port and stbd corners of platform
• Fresh water marina connection pressure regulator
• Hand-held swim shower
• Fresh water deck wash system outlet

• Flybridge deck zone audio with four 8'' Sonance and two 6'' Extreme Speakers with Sonos Amp
• Foredeck zone audio with two 6.5'' Sonance Extreme Speakers with Sonos Amp.
• Aft Deck zone audio with four 8'' Sonance Extreme Speakers with Sonos Amp.
• Salon:
  • Upgraded Samsung 65'' The Frame UHD 4K QLED Smart Television with Apple TV App and AirPlay 2 included with Ultra HD
  • Blu-ray player. Sonance upgraded front and rear speakers with Sonos Amps and Sonos Subwoofer.
• Dining area: two additional Sonance speakers with Sonos Amp.
• Galley: Sonance speakers with Sonos Amp
• Primary Cabin:
  • Samsung 55'' The Frame UHD 4K QLED Smart Television with Apple TV App and AirPlay 2 included with Ultra HD
  • Blu-ray player. Sonance front and rear speakers with Sonos Amps.
• Forward VIP Cabin:
  • Samsung 55'' UHD 4K Smart Television with Apple TV App and AirPlay 2
  • Sonance upgraded speakers with Sonos Amp
• Port Mid Cabin:
  • Samsung 43'' UHD 4K Smart Television with Apple TV App and AirPlay 2
  • Sonance upgraded speakers with Sonos Amp
• Starboard Mid Cabin:
•  Samsung 32'' HD Smart Television with Apple TV App
• Sonance upgraded speakers with Sonos Amp
• Crew:
• 24" HD Television in the crew mess and each of the cabins
• Fusion 770 Apollo head unit for AM/FM radio, USB input, Bluetooth, and Apple AirPlay connectivity to users' devices with two Fusion ceiling speakers.

Main Galley Equipment

• Custom Integrated Refrigeration. Frigoboat with stainless steel interior. 250 litres fridge capacity and 120 litres freezer capacity
• Additional under-counter Frigoboat stainless steel drawer refrigeration
• Miele ceramic (4) burner Cooktop
• Miele Oven
• Miele integrated extractor fan
• Miele Full-size Dishwasher
• Nickel Grey Cabinetry
• Breakfast Bar with 2x Barstools
• Quartz countertop and backsplash
• Additional storage locker fitted above the galley breakfast bar.

Salon

• Miele Wine Cooler for 34 bottles

Guest Hallway

• Spendide  washer/dryer combo unit

Cockpit

• Dometic 50-liter refrigerator

Flybridge

• 2x Frigoboat stainless steel drawer refrigerators
• Icemaker - Hoshizaki
• Kenyon Electric BBQ grill

Crew Mess

• GE microwave oven
• Dometic Coolmatic Refrigerator with integral Freezer box
• Bosch Washing Machine
• Bosch Dryer

Accommodation for up to 8 guests in 4 cabins; and up to 4 crew in 2 cabins, as follows:

Flybridge

• Upper Helm Station
• Wetbar
• Dining Area
• Forward and Aft Lounge Seating

Main Deck

• Main Salon
• Dining Room
• Galley
• Helm Station
• Day Head

Lower Deck

• Primary Cabin
• VIP Cabin
• Double Guest Cabin
• Twin Cabin
• Crew - 2x Twin Crew Cabins with single head and separate shower

MAIN DECK

Main Salon/Dining

• Open plan layout between the salon, dining area, and galley.
• Large sectional sofa and coffee table
• Media console with storage
• Aft and starboard sliding glass doors
• Formal wooden dining table with eight upholstered dining chairs
• Built-in credenza, cabinetry, and shelving/storage in dining area
• Wraparound windows with upgraded electrical window treatments
• Oak wood flooring throughout

Main Helm Station

• Flint Gray Helmseat
• Helm pantograph-style access door to the side deck
• Equipment - see Navigation

LOWER DECK

Primary Cabin

• Starboard side L-shaped sofa and coffee table
• Starboard vanity with stool
• King-size bed with upholstered headboard panels above
• Built-in nightstands on either side with overhead sconce lighting
• Built-in cabinetry/credenza portside
• Samsung 55'' The Frame UHD 4K QLED Smart Television
• Electric window blinds
• Walk-in closet

Primary Ensuite

• Dual vanity sinks
• Ample cabinetry/storage
• Large mirror above vanity
• Marble flooring, tile, and vanity top

VIP Cabin

• Centerline upholstered king-size bed
• Full-width, upholstered headboard/wall panels
• Modern LED strip lighting overhead
• Sleek wall sconces  and reading lights on either side
• Triangular wooden nightstands on each side
• Built-in cabinetry
• Large mounted flat-screen TV
• Windows on either side with porthole
• Carpet
• Ensuite with marble accents and walk-in shower

Guest Cabin

• Full-size bed with upholstered headboard/wall panels
• Built-in nightstand with storage
• Modern LED strip lighting overhead
• Sleek wall sconce above the beds and reading lights on either side
• Oversized hull window with porthole
• Wall-mounted flat screen TV
• Double closet doors with floor-length mirrors
• Carpet
• Ensuite with marble accents and walk-in shower

Twin Guest Cabin

• Two twin beds
• Center shared nightstand
• Upholstered wall panels behind each bed
• Modern LED strip lighting overhead
• Sleek wall sconce between the beds and individual reading lights mounted above each
• Large hull window with a porthole
• Floor-length mirror
• Carpet
• Ensuite with marble accents and walk-in shower

• AB Inflatables Jet Tender AB465X with fiberglass hull and inflatable rib
  • Motor: BRP US – 125KW - model: 440104AMA
  • Garmin Echomap UHD2 94sv
  • 2x JL Audio speakers M6-650X

The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
